Object ID Object Name

Modbus

Address

Active Text Inactive Text PV Access

BI16 BYP DI-7 STAT 8781H: bit 6 ON OFF R

BI17 BYP DI-8 STAT 8781H: bit 7 ON OFF R

BI18 BYP DO-1 STAT 8782H: bit 0 ON OFF R

BI19 BYP DO-2 STAT 8782H: bit 1 ON OFF R

BI20 BYP DO-3 STAT 8782H: bit 2 ON OFF R

BI21 BYP DO-4 STAT 8782H: bit 3 ON OFF R

BI22 BYP DO-5 STAT 8782H: bit 4 ON OFF R

BI23 BYP DO-6 STAT 8782H: bit 5 ON OFF R

BI24 BYP DO-7 STAT 8782H: bit 6 ON OFF R

BI25 BYP DO-8 STAT 8782H: bit 7 ON OFF R

BI26 BYP DO-9 STAT 8783H: bit 0 ON OFF R

BI27 BYP DO-10 STAT 8783H: bit 1 ON OFF R

Binary Output Objects

Table C.8 Binary Output Objects

Object ID Object Name

Modbus

Address

Active Text Inactive Text PV Access

BO1 MF Output M1-M2 0009H:bit 0 ON OFF C

BO2 MF Output M3-M4 0009H:bit 1 ON OFF C

BO3 MF Output M5-M6 0009H:bit 2 ON OFF C

BO4 Ref Sel: PI Setpoint 000FH:bit 1 ON OFF C

BO5 Ref Sel: Term S5 IN 8480H:bit 8 ON OFF C

BO6 Ref Sel: Term S6 IN 8480H:bit 9 ON OFF C

BO7 Refl Sel: Term S7 IN 8480H:bit 10 ON OFF C

BO8 BYP DO-07 COMMAND 8403H:bit 6 ON OFF C

BO9 BYP DO-08 COMMAND 8403H:bit 7 ON OFF C

B010 BYP DO-09 COMMAND 8403H:bit 8 ON OFF C

B011 BYP DO-10 COMMAND 8403H:bit 9 ON OFF C

Binary Value Objects

Table C.9 Binary Value Objects

Object ID Object Name

Modbus

Address

Active Text Inactive Text PV Access

BV1 Not Used BV1 – – – –

BV2 Not Used BV2 – – – –

BV3 Ext Fault Cmd 8480H:bit 2 FAULT OFF C

BV4 Fault Reset Cmd 8480H:bit 3 RESET OFF C

BV5 Not Used BV5 – – – –

BV6 Not Used BV6 – – – –

BV7 MF Input 3 Cmd 8480H:bit 6 ON OFF C

BV8 MF Input 4 Cmd 8480H:bit 7 ON OFF C

BV9 MF Input 5 Cmd 8480H:bit 8 ON OFF C

BV10 MF Input 6 Cmd 8480H:bit 9 ON OFF C

BV11 MF Input 7 Cmd 8480H:bit 10 ON OFF C

BV12 Set Fault Contact Cmd 0009H:bit 6 ENABLE OFF C

BV13 RUN-STOP 0020H:bit 0 RUN OFF R

BV14 REV-FWD 0020H:bit 1 REV FWD R

BV15 READY 0020H:bit 2 READY OFF R

BV16 FAULT 0020H:bit 3 FAULTED OFF R

C.6 BACnet Objects Supported

366

YASKAWA ELECTRIC SIEP YAIZ1B 01D YASKAWA AC Drive – Z1000 Bypass Technical Manual
